54799 RC TT02 Hi-Torque Servo Saver - w/ Aluminum Horn
RC TT02 Hi-Torque Servo Saver - w/Aluminum Horn
This set includes a hi-torque servo saver and dedicated TT-02 design aluminum servo horn to protect internal servo gears and give more direct steering feel to your car.
- Hi-Torque Servo Saver (Black) x1 (Item 51000)
- TT-02 Aluminum Servo Horn x1
- Screws for attachment included.
- Compatible with all TT-02 chassis variants.
Tamiya nummer: 54799
EAN nummer: 4950344547999
DSSERVO BLS4355 Brushless 61KG/0.009sec@8.4V
DSSERVO BLS4355 Brushless 61KG/0.009sec@8.4V
DSSERVO BLS4355 - Brushless digital servo with up to 61kgcm torque
Features:
- Highly efficient brushless motor for maximum power and smooth operation
- Up to 61kgcm torque at 8.4V ideal for large scale models, crawlers and high-end 1/8 vehicles
- Full metal case for optimal heat dissipation and maximum durability
- Dual ball bearings and high gear reduction (ratio 365:1) for high precision
- Waterproof to IP67 perfect for tough off-road and competition use
- Wide operating voltage range from 4.8V to 8.4V
Technical specifications:
| Voltage: | 4.8V | 6.0V | 7.4V | 8.4V |
| Torque: | 39kgcm | 47kgcm | 55kgcm | 61kgcm |
| Speed: | 0.14 sec/60° | 0.12 sec/60° | 0.10 sec/60° | 0.09 sec/60° |
| Motor: | Brushless digital | |||
| Gear train: | All metal | |||
| Bearings: | Dual ball bearings | |||
| Case: | Full metal, waterproof IP67 | |||
| Dimensions: | 40.8 × 20.2 × 29.5mm | |||
| Weight: | 85g | |||
| Operating range: | Control angle 180° / 270° (PWM 500–2500µsec) | |||
| Frequency: | 50–330Hz | |||
| Deadband: | 2µsec | |||
Sanwa PGS-CL2 Low Profile SXR Response (0.08s/16.6kg/7.4V) Coreless Servo
Sanwa PGS-CL2 Low Profile SXR Response (0.08s/16.6kg/7.4V) Coreless Servo
- Programmable Servo to be compatible with SSL & Telemetry at Launch
- Setting Adjustment by wireless from Radio
- Setting Adjustment to connect Servo with Setting Gear
- Regarding Temperature, Current, Voltage and Volume Position on Servo inside, Telemetry-transmission can be passed to Radio.
# Initial Setting on Setting Gear is necessary.
- FH5U: SXR(Sanwa Xtreme Response) Mode-Compatible
- SSL-Compatible Programmable Servo
# Compatible with CODE 10 (M12S, EXZES ZZ, MT-44). Not Compatible with CODE 5 (M12, EXZES Z, MT-4S, MT-4, MT-S)
- PGS Setting Gear-Compatible
- Super Response (SSR) Mode-Compatible
- High Response (SHR) Mode-Compatible
- Li-Po 2 CELL-Compatible
- Low Profiled
- High Torque Type
- Brushless Motor
- Full Aluminum Case
- Full Metal Gear (Strengthening Gears)
- AL Heat Sink
- Black Harness
Setting Items:
- SSL-CH (SSL Channel Setting)
- STRETC (Stretcher Adjustment)
- BOOST (Boost Adjustment)
- D-Band (Dead Band Adjustment)
- MV-MID (Middle Torque Adjustment)
- MV-END (Later Torque Adjustment)
- BREAK (Break Adjustment)
- MV-HOLD (Power Adjustment at whole area)
- MV-FRQ (Feeling Adjustment at whole area)
- MAX-PW (Max Duty Adjustment)
- PGS-Servo Explanation
# Setting Gear is necessary for â—Žsetting.
Specifications:
| Speed (7.4V) | 0.08 sec/60° |
| Speed (6.0V) | 0.11 sec/60° |
| Torque (7.4V) | 16.6 kg/cm |
| Torque (6.0V) | 14.7 kg/cm |
| Dimensions | 40.5x20.5x26.5mm |
| Weight | 49.6g |
Traxxas Servo, Digital High-torque, Metal Gear (ball Bearing), Water, Trx2085x - 2085X
Traxxas Servo, Digital High-torque, Metal Gear (ball Bearing), Water, Trx2085x
YellowRC 30kg Digital Waterproof Servo Trx2075 Replacement + Free Extension Wire - 2075
YellowRC 30kg Digital Waterproof Servo Trx2075 Replacement + Free Extension Wire
